ZIMM KGTØ4040TIPOMSZ50+ECROUMSZ-50+BOITIERMSZ5

ZIMM KGTØ4040TIPOMSZ50+ECROUMSZ-50+BOITIERMSZ5

GSZ-50-RN KG40x40-RH-L3843-KGF-GLP
ZIMM
10063211

SCREW +NUT +BOITIER
ZIMM worm gear screw jack for rotating spindle,
GSZ-50-RN, max. 50kN static, i= 7:1
Housing: ductile cast iron GGG, primed, standard BS1 RAL 7021 (black-grey), NDFT 40?m,
Seals: NBR
Lubrication: Standard grease (also suitable for the food industry)
Optileb GR UF 00
Ball screw drive for screw jacks with rotating spindle,
GSZ-50-R-KG, KG 40x40, Cdyn = 35kN, made of steel, rolled,
Pitch accuracy 0.05 mm / 300 mm
Total spindle length Lb = 3843 mm,
Installation dimension Y: 3850 mm (gearbox side F to spindle end)
End machining 1 (spindle side): Ø 25j6 / 30 mm
End machining 2 (gearbox side): Standard EB for R gearbox
Lubrication (KG nut only): Grease for low temperature and KGT
Tribol GR 4747/220-2 HT
incl. KG flange nut, D1 / L2 = Ø63 / 85mm, assembled
(flange on gearbox side)
SUPPLIED LOOSE:
Counter bearing plate,
GSZ-35/50-GLP



Estimated Delivery 7 Weeks.

Factory Order
