WIKA TR10DZZZZ13DRJS1DZZADIGL5EFA0100010ZZZZ

Resistance thermometer
WIKA
P/N TR10-D-ZZZZ-13DR-JS1D-ZZ-ADIGL5EFA-0100010-ZZ-ZZ

TR10-D Miniature-RTD with integrated protection tube
1xPt100, 3-wire
Class B, IEC 60751
Temperature range of selected class: -50...+250°C
Head / housing: JS, Aluminum
Cable entry: Standard cable entry
Thread size cable entry: M16 x 1.5
Transmitter: Without (terminal block)
Measuring insert: Removable
Connection to neck tube: M10 x 1
Protection tube: With threaded process connection
Protection tube diameter: 6x1 mm
Protection tube material: Stainless steel 1.4571
Process connection: Double threaded hex bushing
Thread size: G 1/2 B
Material process connection: Stainless steel 1.4571
Neck length [MH/N]: 10 mm
Insertion length [A]: 100 mm
Diameter measuring insert: 3 mm
Sheath material measuring insert: Stainless steel 1.4571
Measuring insert length (spare) [l5]: 118 mm

Estimated Delivery 4 Weeks.
