OMC LL1016020

2 Way Globe Control Valve "Air-D"
LL1016020
DN20 PN16 EN1092-2

Mat: Ductil Iron EN-GJS-
400-15, Face to Face Dim. EN558-1 (DIN-UNI)
BLL10020A Standard Bonnet (T.-5÷200°C) AIR-D
LL200 Stuffing box LP200 (PTFE+Carbographite)
TLL10020AB Plug Cv=7.5 EQP Characteristic, PTFE/GR Soft Seated Cl.VI ANSI FCI 70-2, Mat.
Seat & Plug ASTM A182 F304 AIR-D
AL23RA Multi-spring Diaphragm Actuator Ø230 mod.AM23, Semi-Integral Yoke, Signal 3÷
15psi -NC-, stroke 20mm
(Actuator Ø230 which replaces the old one Ø280 mm)

Estimated Delivery 4 Weeks.
