BAUER BS10Z54VODHE06LA6ST

Worm gear motor
BAUER
BS10Z-54VO/DHE06LA6-ST

*************************************

0,12 KW
1,3 upm
158 NM
Service factor: 1.0
Corrosion protection: Standard
RAL7031
Installation: H1
Terminal box position: II / C
Net weight: approx. 25kg
UT: -20 to +40 °C
Rating plate additionally stamped with 60Hz +/-5%
With torque support on top front side
Hollow shaft with keyway - D=30mm
Overlap: i=905,6
2 rubber buffers are supplied loose
Lubricant grade: PGLP 220
Motor:
440V Y
1110 rpm
60Hz
Heat class: F
IP65
IE2

Special version:
Harting plug connection HAN 10 ES
According to dimension drawing TBS11.-06-A3 and connection diagram HS10000000/01
Add-on housing 09 300 100 301 - 2 brackets
Pin insert 09 330 102 616
Cover 09 300 105 407

Estimated Delivery 6 Weeks.
