ASHCROFT E9260B0

Pressure switch model B4
ASHCROFT

B4=24=V=10IW=IP=06=FS=MD

Switches for industrial use
Housing made of aluminum, epoxy resin coated
Protection class IP66/NEMA 4X
Switching accuracy 1%
B4 Pressure switch model B4
24 microswitch SPDT for general application,
15A 125/250/480 Vac, ½A 125 Vdc, ¼A 250 Vdc, 6A 30 Vdc
V Diaphragm material Viton
IP Industrial version Protection class IP66
06 Process connection 1/2 NPT external / 1/4 NPT internal
FS Factory set switching point
MD Metric measuring range
Measuring range: 10 in.H2O / 25 mbar
MD: mm H2O
FS: 90% increasing

Estimated Delivery 3 Weeks.
